Posts posted by 560Dennis

  1. 9 hours ago, Tj01 said:

    So I called BK Diesel in Iowa and they had the seal kit in stock!! It will be here Tuesday of next week then I can tear into that and fix that leak and hopefully the tractor will be better than ever. It still wants to hunt some in the governor on the throttle. I’m gonna try and put it under a hard load when it will stop raining. Bolted the hood and grill on the other day and it really looks good to be all original!!



    Looking good , keep us posted

    • Thanks 1
  2. Working 1948 C . We added a water pump ,don’t remember ! or could have been from the engine I got from Charlie Burgh. I guy just doesn’t remember.
    Noticed the coolent was cool . So Super C s have  a thermostat. I wanted to ad a thermostat. Putting in a new headgasket for water pump and head work , to correct the wear .
    How does guy add a thermostat without a super c housing?
    I have a siphon feed housing. Well after some thought about this . Measurements of the opening come to 2.062 , well a thermostat has a flange of 2062 .is available . Went Andy’s auto parts, like going there cause he will give me advice and opinion even if he doesn’t get the sale. He said this themostat has a 2.062 flange .
    I thought I would braze it into the housing to hold. Andy said how about JB weld . Bette yet ,I wasn’t  good at heating the and holding it in location. JB weld I could manage.
    So this is the result. Putting a thermostat into a siphon housing .

    Next step is trail , and measure the temperature of exiting coolent.
    photos are for your edification and amusement.


  3. Working 1948 C . We added a water pump ,don’t remember ! or could have been from the engine I got from Charlie Burgh. I guy just doesn’t remember.
    Noticed the coolent was cool . So Super C s have  a thermostat. I wanted to ad a thermostat. Putting in a new headgasket for water pump and head work , to correct the wear .
    How does guy add a thermostat without a super c housing?
    I have a siphon feed housing. Well after some thought about this . Measurements of the opening come to 2.062 , well a thermostat has a flange of 2062 .is available . Went Andy’s auto parts, like going there cause he will give me advice and opinion even if he doesn’t get the sale. He said this themostat has a 2.062 flange .
    I thought I would braze it into the housing to hold. Andy said how about JB weld . Bette yet ,I wasn’t  good at heating the and holding it in location. JB weld I could manage.
    So this is the result. Putting a thermostat into a siphon housing .

    Next step is trail , and measure the temperature of exiting coolent.
    photos are for your edification and amusement.








    • Like 4
  4. On 3/16/2024 at 12:09 PM, twostepn2001 said:

    Dukes of Hazzard?? l figured your TV would be on "Graveyard Carz".....lol  Good 'ol Mark Worman!!


    Hero’s and villain’s! ,sinners and saints! . If Mark Worman was not born god would create him !





    • Haha 1
  5. I would not use that from what I’m seeing so far. Why because as you spin the sleeve , mangle end with cut if it caught will rip open your palm  .  spend the money and get a decent crank , eliminating the pain .
    I’ve made replacement sleeve with painful results. The sleeve has to have all the sleeve rotated .no fixed surface such as ( shaft collars ) for the hand to pinch between fixed crank and rotating. This is must do. Absolutely no pinch points
    I recommend that the starting system on tractor to be repaired and use crank only in a case where it is absolutely necessary.


    • Like 3
  6. Interesting post , seem to me I saw some thing similar  on motortrend about a hop up . They used a sealing ring after they blown a headgasket .
    Never caught which head gasket was ok for the higher pressure from more boost

  7. Basically they are all the same !


    Chevy Small Block V8 Engine Block Casting Numbers
    CASTING#.....SIZE...YEAR...MAIN CAP BOLTS....NOTES

    140029.....350...80-84...2 Bolt Main
    330817.....400...73-76 Passenger 75-80 Truck..2 Bolt Main
    355909.....305...78-79 Passenger 76-79 Truck
    355909.....305...76-79...2 Bolt Main
    360851.....262...75-76...2 Bolt Main...Monza V-8
    361979.....305...76-79...Passenger 76-79 Truck 2 or 4, Bolt Main
    366245.....350...78-79...Passenger
    366286...................4 Bolt Main...Bowtie, 2-piece seal, 4.00-4.150" bores, 2.45" main journals
    366298...................4 Bolt Main...Bowtie, 3.398" bore with sleeves, two piece rear main seal.
    366299...................4 Bolt Main...Bowtie, 4.00" bore
    389257.....302.....67....2 Bolt Main
    393288.....283...65-67...2 Bolt Main
    460703.....350.....78....4 Bolt Main
    460776.....305...78-79...Passenger 2 Bolt Main
    460776.....305...78-79 Truck 2 Bolt Main
    460777.....305...78-79...2 Bolt Main
    460778.....305...78-79...2 or 4, Bolt Main,
    471511.....267...79-82...2 Bolt Main
    3556519....283...58-61...2 Bolt Main
    3703524....265.....55....2 Bolt Main...No oil filter 55 Corvette 195 Hp
    3720991....265...56-57...2 Bolt Main
    3731548....265...57......2 Bolt Main...No side motor mounts
    3731548....283...57......2 Bolt Main...No side motor mounts
    3737739....283...58-64...2 Bolt Main
    3756519....283...58-62...2 Bolt Main
    3782870....327...62-67...2 Bolt Main
    3789817....283...62-64...2 Bolt Main
    3789817....327...62-67...2 Bolt Main
    3789935....283...61-64...2 Bolt Main
    3790721....283...62-64...2 Bolt Main...Chevy II recessed oil filter boss
    3790721....327...65-66...2 Bolt Main...Chevy II recessed oil filter boss
    3791362....327...62-67...2 Bolt Main...Chevy II recessed oil filter boss
    3792563....327.....65....2 Bolt Main
    3792582....283...64-65...2 Bolt Main
    3794226....283...58-63...2 Bolt Main
    3794460....327...62-64...2 Bolt Main
    3830944....327.....63....2 Bolt Main
    3834810....283...64-66...2 Bolt Main
    3834812....283...62-63...2 Bolt Main
    3837739....283...58-62...2 Bolt Main
    3849852....283...57-66...2 Bolt Main
    3849935....283...65-67...2 Bolt Main
    3858174....327...64-67...2 Bolt Main
    3858180....327...64-67...2 Bolt Main
    3858618....350...68-76...2 Bolt Main
    3862194....283...65-67...2 Bolt Main...Chevy II recessed oil filter boss
    3862812....283...62-64...2 Bolt Main
    3892657....302.....67....2 Bolt Main...Z-28 Camaro
    3892657....327.....67....2 Bolt Main
    3892657....350.....67....2 Bolt Main...Camaro
    3896944....283...66-67...2 Bolt Main
    3896948....283...66-67...2 Bolt Main
    3903352....327.....67....2 Bolt Main
    3914636....307.....68....2 Bolt Main
    3914638....327.....68....2 Bolt Main...Truck
    3914653....307...68-73...2 Bolt Main
    3914660....327.....68....2 Bolt Main
    3914678....302.....68....2 Bolt Main...Z-28 Camaro
    3914678....327.....68....2 Bolt Main
    3914678....350.....68....2 Bolt Main
    3931174....307.....68....2 Bolt Main...Truck
    3932371....307...69-73...2 Bolt Main
    3932373....307...68-73...2 Bolt Main
    3932386....302.....69....4 Bolt Main...Z-28 Camaro
    3932386....327.....69....2 Bolt Main
    3932386....350.....69....4 Bolt Main
    3932388....327.....69....2 Bolt Main
    3932388....350.....69....2 or 4 Bolt Main
    3933180....327...68-69...2 Bolt Main
    3951509....400...70-71...4 Bolt Main
    3951509....400...74-80...2 Bolt Main
    3951511....400...70-73...4 Bolt Main...Some replacement blocks had 2-bolt main caps
    3956618....302.....69....4 Bolt Main...Z-28 Camaro
    3956618....327...68-69...2 Bolt Main
    3956618....350.....69....2 or 4 Bolt Main
    3956632....307.....69....2 Bolt Main
    3959512....327...62-67...2 Bolt Main...Was also used for some "CE" replacement blocks
    3959532....283...64......2 Bolt Main...Used for some "CE" replacement blocks
    3970010....302.....69....4 Bolt Main...Z-28 Camaro
    3970010....327.....69....2 Bolt Main...Trucks and industrial
    3970010....350...69-80...2 or 4 Bolt Main
    3970014....350...70-76...2 or 4 Bolt Main
    3970020....307...70-73...2 Bolt Main
    3970024....307...69-73...2 Bolt Main
    4715111....305.....80....2 Bolt Main
    6259425....350...69-76...2 Bolt Main
    10036033...350...........4 Bolt Main...Goodwrench crate motor, 2-piece rear seal,
    10046164...305.....86....2 Bolt Main
    10051182.................2 or 4 Bolt Main...Bowtie, 3.75"-4.30" bores, 1 or 2-piece rear seal
    10051184.................4 Bolt Main...Bowtie, 4.00"-4.155" bores, 1 or 2-piece rear seal
    10054727...350...86-up...2 or 4 Bolt Main...one piece rear seal
    10066036...350...........2 or 4 Bolt Main...Target Master/Goodwrench crate motor, 2-piece rear seal
    10066038...350.....92....4 Bolt Main...Goodwrench crate motor, 2-piece rear seal,
    10090511...350.....90....2 Bolt Main...LT-5, ZR1 Vette, 375hp
    10125327...350...92-up...2 or 4 Bolt Main...Gen.II LT-1, reverse flow cooling
    10125327...350...96-up...2 or 4 Bolt Main...Gen.II LT-4, reverse flow cooling
    10134996.................4 Bolt Main...Bowtie, Aluminum, 4.125" bore 2.65" main journals
    10153558...350...91-92...4 Bolt Main...LT-5, ZR1 Vette, 375hp
    10168588...265...94-96...2 Bolt Main...L99, Gen.II, 4.3 Liter V-8, Caprice, reverse flow cooling
    10199001...350...93-95...4 Bolt Main...LT-5, ZR1 Vette, 405hp
    10243878...305...96-98...2 Bolt Main...Vortec truck, roller cam, one-piece rear seal
    10243880...350...95-00...2 or 4 Bolt Main...Vortec truck, Gen.I crate motors and "ZZ4", roller cam, one piece rear seal
    12550592...350...97-up...crossbolted block, Gen.III, "LS1", aluminum
    12551354...364...02-up...crossbolted cast iron Gen. III, 6.0L, truck
    12559378...350...99-up...crossbolted block, Gen.III, "LS1", aluminum
    12559846...350...98-up...crossbolted block, Gen.III, "LS1", aluminum
    12560621...350...98-up...crossbolted block, Gen.III, "LS1", aluminum
    12560626...350...99-up...crossbolted block, Gen.III, "LS1", aluminum
    12560629...350...99......crossbolted block, Gen.III, "LS1", aluminum
    12561168...350...01-up...crossbolted block, Gen.III, "LS1", aluminum
    12561358...293...99-up...Gen.III, Used with 4.8L motors
    12561358...325...99-up...Gen.III, used with 5.3L motors
    12562174...350...98-up...crossbolted block, Gen.III, "LS1", aluminum
    12577396.........02-up...Gen.III, 4.8L or 5.3L, cast iron, truck
    14010201...305...80-85...2 Bolt Main
    14010202...305...80-85...2 Bolt Main
    14010203...305...80-85...2 Bolt Main
    14010207...350...80-85...2 or 4 Bolt Main
    14010209...350...80-85...2 or 4 Bolt Main
    14010280...267...79-82...2 Bolt Main
    14011064...350...83......4 Bolt Main
    14011148...350...87-89.......Roller cam, one-piece rear seal
    14016376...267...79-82...2 Bolt Main
    14016379...350...77-79...2 or 4 Bolt Main
    14016381...305...80-84...2 Bolt Main
    14016382...305...79-84...2 Bolt Main
    14016383...305...80-85...2 Bolt Main...Truck
    14079287...350...86-90.......Truck
    14088526...350...87-89.......Roller cam, one-piece rear seal
    14088548...350...86-88...2 or 4 Bolt Main
    14088551...305...86-87...2 Bolt Main...one-piece rear main seal
    14093627...305...87-91...2 Bolt Main...Roller cam, one-piece rear seal
    14093638...350...87-95...2 or 4 Bolt Main...Roller or flat tappet cam one-piece rear seal
    14094766...305...86-up...2 Bolt Main...One-piece rear seal
    14101147...305...85-up...2 Bolt Main
    14101148...350...87-90...4 Bolt Main...One-piece rear seal
    14102058...305...87-91...2 Bolt Main...Roller cam, one-piece rear seal
    22551656.................4 Bolt Main...Rocket block, 4.00"-4.190" bores, 2.45" main journal sizes, splayed caps, dry sump, 2-piece rear seal, 9.025" deck.

    • Like 1
  8. 10 hours ago, vtfireman85 said:

    Its not something i was really considering, just popped up and i was curious. I hear raving about 327’s and I also know that truck engines tend to be heavier parts but lower compression. Just looking to learn something.

    Good for turbos ,with lower compression,right ?

  9. Doing ok I see ,

    I get the bags at Richard’s maple products in Kirkland ,Ohio

    closer to you in Cranesville ,Pa. Is Sugarmaker , post once in awhile , a very good resource

    • Like 1
×
×
